Vesuvio RGBA combines the ferocious intensity of a towering fog output with the visual impact of color mixed LED wash lighting to create dramatic atmospheric columns. Vesuvio RGBA outputs an impressive 40,000 cubic feet of fog per minute. It features a fast and dependable 1.6 kW heater and a 2.5 L fluid tank. It works best with the Chauvet HDF high-density and QDF quick dissipating fluid.
Scenius Profile is the new Clay Paky beam shaper at the top of the Clay Paky moving head range. The optical reflector has been designed specifically for this product, in order to make the projection perfectly uniform across the whole beam opening, avoiding the typical hotspot effect of many spotlights. Its framing system consists of four independent overlapping blades that create shapes of all sizes, not just quadrangular, but also triangular. It works simultaneously on four different focal planes and the exclusive “curtain effect” allows gradual total closure of the shape using any one of the four blades. The shape made may also be turned around itself up to an angle of 90°, either to change its orientation or keep it fixed as the light beam moves.
Its advanced optical unit and the new 1400W OSRAM discharge lamp provide very high light output and CRI. Thanks to its wide 7°-48° zoom, Scenius Profile is perfect for every set. A modern focus tracking system concentrates maximum luminous efficiency precisely on the effect you wish to project, and the focus may be set to be fully automatic.
The CMY color system, the linear CTO, 7 fixed colors, 14 gobos (6 rotating + 8 fixed), rotating prism, 2 variable frost filters, a very precise dimmer enhance the performances of this luminaire.
With all these features, the Scenius Profile is an extraordinary tool for theatrical use, in television studios or on the sets of large events, where it can fashion uniform light beams without limits and frame scenic elements precisely with fixed or animated light.
The optical reflector of Scenius Profile can be replaced with that of Scenius Spot, to obtain a higher luminous peak at the center of the beam.
- 1400W OSRAM discharge lamp
- New optical reflector to ensure perfectly uniform beam projections
- Framing System operating on 4 focal planes
- Framing System rotation on 90°
- 7°-48° zoom
- Focus tracking system
- 6500 K output color temperature
- Very high CRI
- CMY System + Linear CTO
- 7-color wheel
- 14 gobos (6 rotating + 8 fixed)
- Rotating Prism
- 16 blades fast Iris
- Variable “soft edge” frost
- Variable flood frost
- Very precise 0-100% dimmer
- Fast stop/strobe effect
- Light can be run at 1400W or 1200W
- Art-Net / RDM
- Quiet, reliable and road-ready
- Weight: 41 Kg
The Protron 3K™ is a new high powered LED strobe featuring (200) CREE™ 3W Cool White LEDs, 80,000 lumens, 120° beam angle, (2) power modes (HIGH or LOW), strobe effect macros including burst, pulse, lighting, and full ON*, (2) silent cooling fans, electronic dimming, 3/5pin DMX and powerCON in/out connections, (4) button LCD control panel, an integrated rigging yoke, 900W max power consumption, and a multi-voltage universal auto switching power supply (100-240v). *Thermally regulated output at full max 10 seconds.
The ZW19™ is an LED moving head beam/wash effect luminaire featuring (19) 10W RGBW 4-in-1 LEDs, motorized 10° to 60° zoom, 64 color macros, fast and precise 540° pan and 220° tilt rotation, 16-bit fine resolution adjustable movement, strobe, and selectable dimming curve effects, 3/5pin XLR and powerCON in/out connections, (4) button control 180° reversible menu display, 245W max power consumption, and a multi-voltage universal auto switching power supply (100-230v).
The Daylight HD and Tungsten HD arrays were designed for the studio and other applications where high-definition lighting is a must. With flicker-free operation – even at high speeds – the Source Four LED Series 2 Daylight HD and Tungsten HD arrays look great on screen. The Daylight HD array produces the coolest (4000 to 6500K), variable-white light that looks just like natural sunlight, and the Tungsten HD array creates warm (2700 to 4500K), adjustable-white light that mimics the performance of tungsten fixtures. Their temperatures and tints can be tweaked to perfectly illuminate individual skin tones, so they look great in person and on camera. Both arrays output an incredible amount of lumens, for the brightest light in their respective color-temperature ranges.
Using technology originally designed for the L7-C Fresnel, the SkyPanel S60-C is fully color “tuneable” allowing output of a warm 2,800K to icy blue 10,000K light and also uses the full RGB+W color gamut with hue and saturation control for fine adjustments. Full Minusgreen to Full Plusgreen is also possible, so if you’re lighting for blue or greenscreen, you can simply dial your color chosen in. This wide degree of control is responsible for a very high CRI of 95 and a rating of 90 with the newer TLCI standard. All of these functions as well as 0-100% dimming can be adjusted locally with the SkyPanel’s onboard controller or remotely via DMX or a LAN. Besides inputs and outputs appropriate to these functions, the light also has a USB-A port for downloading firmware upgrades from a thumb drive, PC or Mac.
The SkyPanel S60-C can be used worldwide, thanks to its included 90-250 VAC power supply but it can also use optional 23-36 VDC batteries when mains power is unavailable. Besides the power supply, the light comes with a Junior (1-1/8″) pin and a standard diffuser. This version of the light has a manual yoke and comes with an Edison power cord.
The BMFL WashBeam will enhance any show with its large beam produced through wide 180 mm front lens. With custom light source designed for Robe it produces an astounding 300.000 lux at 5 metres! Rotating gobo wheel with carefully selected gobos ensure many combinations of in air animations, but can also produce nice spot-like projections on surfaces. Four fast shutter blades with smooth and precise movement offer individually angled positions within a frame – which itself can rotate through 90 degrees, providing a sharp or soft, precisely repeatable frame for the projected image. Fast movement of the framing system also allows unique in air beam effects. Adding frost fi lters can enhance the projection by adding smooth touches to the beam‘s edge.
Designed specifically as the market leading mid-air effects fixture, the VL6000 Beam sets a new standard in its class. A large 14” front aperture – using a new exclusive Philips ellipsoid reflector array system – produces a retro style searchlight effect, with a high output tight collimated shaft of light at 6.5.
Its light weight robust construction and stylish compact design, allows the fixture to transport and install easily, while its visual effects offer something truly spectacular for arena applications.
The new CUEPIX Panel™ features (25) long life 30W 3-in-1 RGB COB LEDs, a 60° beam angle, RDM (Remote Device Management), individual control of each COB module, variable / selectable dimming curves, strobe and zone chase effects, flicker free operation for TV and Film, ArtNet™, KlingNet™ and RDM (remote device management) protocol support, 3pin and 5pin DMX and powerCon in/out connections, LCD menu display with 4 button control panel, integrated rigging points and optional rigging bracket available, and a multi-voltage universal auto switching power supply (100-250v).
