Ayrton’s latest innovation, Diablo, is a versatile, feature-rich 300 W profile luminaire based on the ultra-compact Mistral format.

The company has taken on the ambitious challenge of making Diablo the smallest, lightest and most efficient luminaire of its category. With a record output of 19,000 lumens and a total weight of 21.8 kg, DIABLO is a powerhouse of technology that will tempt the most demanding lighting designers. To achieve its objective, Ayrton has miniaturised the framing system while maximizing the performance level. Diablo is available in two versions: S and TC.

Diablo-S, specially designed for stage applications, is equipped with a monochromatic LED light source that can generate extremely high output and metallic white light calibrated at 6500 K.

DIABLO-TC is geared for applications that require perfect colour rendition, using a monochromatic light source with a native colour rendering index greater than 90 and high TM30 readings, at a colour temperature of 5700 K.

• Specifications:
• Optics:
  • 13-element 8:1 zoom high-resolution optic system
  • Beam aperture: 6.7° to 53°
  • Fast motorised linear zoom
  • Tempered anti-reflective coated lenses
  • 119 mm frontal lens for greater performance
• Light Source:
  • Rated life (L70): up to 40,000 hours
  • Flicker-free source management suitable for TV applications and all video-recorded events
• Movement:
  • Extremely accurate positioning
  • Moving-head operated with either 8- or 16-bit resolution
  • High-resolution stepper motors operated via microprocessors to ensure extreme accuracy and smooth movement
  • Pan and tilt with automatic repositioning
  • Moving-head range: 540° (pan), 270° (tilt)
• Colours:
  • Sophisticated colour mix system providing CMY colour mixing
  • Variable CTO colour temperature correction
  • Fixed colour wheel with seven complementary colours
• Gobos:
  • Indexable rotating gobo wheel with 7 high-precision glass gobos, plus open position
  • Adjustable-speed rotating gobo in both directions
  • Gobo diameter: 25.0 mm
  • Image diameter: 20.0 mm
  • Gobo thickness: 1.1 mm
• Framing System:
  • 4 individually positionable shutter blades
  • Rotation of the framing system module: +/- 45°
• Dimmer / Strobe:
  • Electronic dimmer, allowing perfect light adjustment from 0 to 100% without colour variation
  • White or colour strobe effect, with speed adjustment from 1 to 25 flashes per second
• Hardware Features:
  • Integrated wireless CRMX TiMo™ RDM receiver from LumenRadio™
  • XLR 5-pin male and female connectors for DMX connection
  • powerCON TRUE1 male and female connectors for power connection
• Control:
  • DMX 512 protocol, through DMX cable or a wireless system
  • DMX-RDM compatible
  • Choice of 3 DMX modes (from 34 to 56 DMX channels)
• Power Supply:
  • Electronic supply with active PFC
  • 100 to 240 Volts – 50/60 Hz
  • Power: 550 W maximum
• Housing:
  • Moving-head skeleton made of aluminium and steel metal plates
  • Base in die-cast aluminium
  • Aluminium and copper heatsinks
  • Moulded covers in self-extinguishing fire retardant ABS PC (V0 class)
  • Two-side handles for transportation
  • Four heavy-duty feet for better stability
  • IP20 protection rating
  • Exterior finish: black (Carbon)

MAGICBLADE™R is a new design that offers continuous double rotation on PAN/TILT axes. Its unique feature is the layout of its seven RGBW LED sources in-line, paired with the highly intensive angle of the optics, which allow the creation of light curtains with genuine overall consistency. On stage, MAGICBLADE™R’s very high centre beam intensity enables excellent visual perception of the beams in an environment saturated with light – vital in the creation of virtual décor.
AYRTON™ has opted for a compact design for MAGICBLADE™R, with the primary objective of reducing the visual footprint of its luminaires. This allows MAGICBLADE™R to be installed in many unique positions and, coupled with the individual control of the 7 RGBW LED sources, enables the creation of a multitude of new effects.

First-born in the Creative Solutions family, MAGICPANEL-602 is a modular LED luminaire which delivers a broad range of diverse visual effects. Equipped with continuous unlimited PAN & TILT rotation, it is able to display numbers, letters, graphic effects or images, but it is also a fabulous lighting luminaire which can be used as a dazzling projector. This luminaire integrates the new AYRTON technology that allows the individual control of each LED source in expanded Full Colour mode. The display is made up of thirty-six 15 Watt RGBW LED emitters in a 6 x 6 array, fitted with high-output 7.5° 45 mm optics. These offer an overall luminous flux in excess of 14,000 lumen from a maximum power consumption of 600 Watt.

The square shape of the panel and perfect alignment of the optics combined with the continuous double rotation movements permit the creation of completely new three-dimensional effects. MAGICPANEL-602 can be used in groups to create rotating screens on the two axes while the robust construction of the luminaire allows its permanent use in vertical position.

Heat management is handled by a sophisticated and particularly quiet cooling system.

MAGICPANEL-602, which is particularly intended for the creation of special effects, benefits from extensive line connectivity. It can be controlled by DMX-RDM, Art-Net or through the LumenRadio DMX-RDM wireless connection.
