COLORado Solo Batten 4 is a unique RGBAW 4-cell LED batten with seamless end-to-end color mixing. This compact, multi-purpose fixture has four completely homogenized, individually-controlled square sections that project smooth color-mixing without separation or dimmed lens corners. This versatile batten is IP65-rated and can be used as a wash or for pixel-mappable eye-candy effects. It also compliments our COLORado Solo Batten perfectly. This small but robust fixture was built for touring, festivals, installations, and theatrical productions. This unit includes IP-rated power, DMX, and Ethernet connections, as well as a large, password-protected display.

COLORado Solo Bar 1 is a 4-cell IP65-rated RGBwWL LED batten that produces a full range of color and perfect whites from a fixture offering LDs the flexibility to easily create beautiful whites with RGBwW or take control of all five colors in the full RGBwWL array. COLORado Solo Bar 1 seamlessly combines homogenized squares for phenomenal end-to-end direct-view pixel-mapped looks, with the high output and long throw to perform equally well as a cyc, footlight, or traditional batten down light. Its advanced IP65 design brings lighter weight and all-weather durability together in one fixture at home both on the road and in permanent installations. A selection of beam shaping filters is included to broaden the choice of projection effects. Control is via DMX, ArtNet or sACN. With improved and simplified rigging options, virtually silent operation, and flawless performance live or on camera, COLORado Solo Bar 1 brings new versatility to touring, festivals, televised and theatrical productions.

COLORado Solo Bar 4 is a 16-cell IP65-rated RGBwWL LED batten that produces a full range of color and perfect whites from a fixture offering LDs the flexibility to easily create beautiful whites with RGBwW or take control of all five colors in the full RGBwWL array. COLORado Solo Bar 4 seamlessly combines homogenized squares for phenomenal end-to-end direct-view pixel-mapped looks, with the high output and long throw to perform equally well as a cyc, footlight, or traditional batten down light. Its advanced IP65 design brings lighter weight and all-weather durability together in one fixture at home both on the road and in permanent installations. A selection of beam shaping filters is included to broaden the choice of projection effects. Control is via DMX, ArtNet or sACN. With improved and simplified rigging options, virtually silent operation, and flawless performance live or on camera, COLORado Solo Bar 4 brings new versatility to touring, festivals, televised and theatrical productions.

COLORado Solo Bar 6 is a 24-cell IP65-rated RGBwWL LED batten that produces a full range of color and perfect whites from a fixture offering LDs the flexibility to easily create beautiful whites with RGBwW or take control of all five colors in the full RGBwWL array. COLORado Solo Bar 6 seamlessly combines homogenized squares for phenomenal end-to-end direct-view pixel-mapped looks, with the high output and long throw to perform equally well as a cyc, footlight, or traditional batten down light. Its advanced IP65 design brings lighter weight and all-weather durability together in one fixture at home both on the road and in permanent installations. A selection of beam shaping filters is included to broaden the choice of projection effects. Control is via DMX, ArtNet or sACN. With improved and simplified rigging options, virtually silent operation, and flawless performance live or on camera, COLORado Solo Bar 6 brings new versatility to touring, festivals, televised and theatrical productions.

With high-efficiency optics and 14 intense, calibrated tri-colored LEDs, the COLORado 1-TRI IP is an ideal front light. The tri-colored LEDs eliminate multicolored shadows while selectable dimming curves ensure compatibility with an older non-LED rig. Plus, optional (20° and 60° x 1°) color blending filters further enhance this IP66-rated fixture’s outstanding performance. COLORado 1-Tri IP also includes an attachable gel frame holder.

COLORdash Batten-Quad 6 is a linear wash fixture with 6 individually controllable quad-colored RGBA LEDs outputting any variation of white as well as richly saturated colors, thanks to the inclusion of amber LEDs. It pixel maps beautifully when used in multiples because it maintains an even pixel pitch. Setup is easy with a hanging bracket, floor trunnions, 3- and 5-pin DMX connectors and secure Neutrik® powerCON® power in and out.

The Chauvet COLORdash Batten TRI is a multi-par lighting effect with 8 tri-color LED lights in a mountable fixture. Pixel mode enables individual control over each of the 8 high-powered LEDS, giving the user the flexibility to create intricate runaway effects. The COLORdash Batten TRI is DMX controllable and an ideal choice for stage lighting, architectural up-lighting, DJs, bands and more.

• LIGHT SOURCE & OPTICAL SPECIFICATIONS
• Light Source: 7 LEDs (quad-color RGBA) 15 W, (985 mA)
• Light Source Lifespan: 50,000 hours based on LED manufacturer’s specifications
• Installed Optics: 15°
• Beam Angle: 16°
• Field Angle: 27°
• Lumens: 1,176
• Base Illuminance: 880 lux @ 5 m
• Efficacy: 22.9 lm/W
• Minimum Distance to Illuminated Surface: 4 in (92 mm)

• CONSTRUCTION & PHYSICAL SPECIFICATIONS
• Length: 10.2 in (260 mm)
• Width: 5.1 in (130 mm)
• Height: 10.4 in (265 mm)
• Weight: 10.8 lb (4.9 kg)
• Color: Off white
• Ingress Protection Rating: IP65
• Housing Material: Cast aluminum
• Lens Cover: Impact resistant glass
• Installation Orientation: Product aperture vertical up +/- 170°

• CONTROL SPECIFICATIONS
• Control Protocol: USITT DMX-512a
• Control Channels: 4, 6 or 10
• Standalone Control: Yes
• Data Connection: 6.6 ft (2 m) Waterproof cable
• Accessories (optional): IP5SIG IP signal extension 16.4 ft (5 m)

• ELECTRICAL SYSTEM SPECIFICATIONS
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current:
  • 52 W, 0.44 A @ 120 V
  • 51 W, 0.24 A @ 230 V
• Power Supply: Electronic internal
• Dimmer: Electronic
• Power Linking: 23 units @ 120 V, 38 units @ 208 V, 42 units @ 230 V
• Power Connection: 6.6 ft (2 m) Waterproof cable, Edison plug to proprietary IP65 input power cord
• Accessories (optional): IP5POWER IP power extension 16.4 ft (5 m)

• THERMAL SPECIFICATIONS
• Cooling: Convection
• Startup Temperature Range: -4 °F to 104 °F (-20 °C to 40 °C)
• Operating Temperature Range: -20 °F to 110 °F (-29 °C to 43 °C)
• Storage Temperature Range: -40 °F to 167 °F (-40 °C to 75 °C)

Épix Bar Tour is a pixel-mapping 1-meter LED bar, featuring 150 LEDs in three rows and a 125 degrees viewing angle. Use the Épix Drive 900 to power and control it on Art-Net, Kling-Net, or sACN (streaming ACN).
