Lighting

Mythos is a highly advanced form of hybrid light: first of all, it is an excellent 470 watt-lamp spotlight, which produces an outstanding large light beam, featuring a zoom that ranges from 4° to 50° (1:12 ratio).

Light beam is sharp, with perfectly defined edges, from the first millimetres after the front lens right along its entire length. The zoom is optimized for focusing, which is separate from that of the fixed and rotating gobos. Its movements are smooth, fast and very quiet. Mythos also features a completely redesigned indexed visual effect disc, which may be superimposed on all the gobos, both in and out of focus.

But Mythos is also an extraordinary beam light, allowing you to switch to a minimum fixed beam angle of just 2.5°. A large, very dense, 160 mm-diameter light beam leaves the Mythos’s front lens and remains parallel for its entire length even at great distances.

Mythos is a very versatile tool, which is useful in any situation and therefore an excellent investment.

• 470W, 7800K discharge lamp
• Large 160mm diameter front lens
• Electronic focusing for a perfectly sharp light beam along its entire lenght
• 4°- 50° electronic zoom (Spotlight mode)
• 2.5° aperture and “pipe” effect (Beam mode)
• CMY color mixing with gradually fading color wheels
• 14 special color filters on three wheel
• 2 CTO filters (3200 K and 2500 K) + 1 CTB filter
• Wheel with 6 HQ dichroic rotating gobos
• Wheel with 18+1 fixed metal gobos
• 6 beam reducer filters on the gobo wheel
• Advanced visual effect disc (animation disc)
• 2 indexable rotating prisms (8-facet and linear 4-facet prism)
• Frost filter for soft-edge projection
• High precision dimmer and stop-strobe effect
• Rapid and extensive pan and tilt movements
• High performance electronics and firmware
• Art-Net / RDM
• Patented Italian Design

Scenius Profile is the new Clay Paky beam shaper at the top of the Clay Paky moving head range. The optical reflector has been designed specifically for this product, in order to make the projection perfectly uniform across the whole beam opening, avoiding the typical hotspot effect of many spotlights. Its framing system consists of four independent overlapping blades that create shapes of all sizes, not just quadrangular, but also triangular. It works simultaneously on four different focal planes and the exclusive “curtain effect” allows gradual total closure of the shape using any one of the four blades. The shape made may also be turned around itself up to an angle of 90°, either to change its orientation or keep it fixed as the light beam moves.

Its advanced optical unit and the new 1400W OSRAM discharge lamp provide very high light output and CRI. Thanks to its wide 7°-48° zoom, Scenius Profile is perfect for every set. A modern focus tracking system concentrates maximum luminous efficiency precisely on the effect you wish to project, and the focus may be set to be fully automatic.

The CMY color system, the linear CTO, 7 fixed colors, 14 gobos (6 rotating + 8 fixed), rotating prism, 2 variable frost filters, a very precise dimmer enhance the performances of this luminaire.

With all these features, the Scenius Profile is an extraordinary tool for theatrical use, in television studios or on the sets of large events, where it can fashion uniform light beams without limits and frame scenic elements precisely with fixed or animated light.

The optical reflector of Scenius Profile can be replaced with that of Scenius Spot, to obtain a higher luminous peak at the center of the beam.

• 1400W OSRAM discharge lamp
• New optical reflector to ensure perfectly uniform beam projections

• Framing System operating on 4 focal planes
• Framing System rotation on 90°

• 7°-48° zoom
• Focus tracking system
• 6500 K output color temperature
• Very high CRI
• CMY System + Linear CTO
• 7-color wheel
• 14 gobos (6 rotating + 8 fixed)
• Rotating Prism
• 16 blades fast Iris
• Variable “soft edge” frost
• Variable flood frost
• Very precise 0-100% dimmer
• Fast stop/strobe effect
• Light can be run at 1400W or 1200W
• Art-Net / RDM
• Quiet, reliable and road-ready
• Weight: 41 Kg

Sharpy is a 189W moving beam light with an unprecedented brightness usually achievable only with far greater wattages. Weighing just 16 kg, Sharpy produces a perfectly parallel, laser-like beam with an incredible output of 59,760 lx at 20m (5,100 footcandles at 65 ft). Sharpy is also groundbreaking for the purity of its beam, which is sharply defined and free of any halo or discoloration around the edges. It offers 14 different colors and 17 gobos, allowing you to change the shape of the beam and create an array of spectacular mid-air effects.
With its light weight and modest footprint, Sharpy is small enough to be fitted anywhere – on trusses at live and TV events, on stage, in showrooms or conference rooms.

Sharpy is also available in a shiny mirror-finish chrome version, adding glamour to sets while making lights a less invasive presence.

Reviews

“We never thought we’d see a 190W light that we could use in Wembley Arena.”
2010 PLASA Jury

“This is the type of output normally seen with Xenon fixtures, not sub-200W lamps that could pass as carry-on luggage.”
Patrick Dierson, Live Design, February 2011

• 189W discharge lamp (Platinum 5R o Osram Sirius 190 Plus)
• Perfectly parallel, laser-like beam, sharply defined and free of any halo

• Unprecedented brightness – comparable to wattages many times higher (59,760 lx at 20m)

• Adjustable beam angle from 0 to 3.8°

• Interchangeable color wheel with 14 fixed colors

• Interchangeable gobo wheel with 17 fixed gobos

• 8-facet rotating prism
• Mechanical dimmer
• Frost Filter

• Rapid and extensive pan and tilt movements

• New, high-performance electronics

• Patented Italian design

• Small, lightweight and easily transported (only 48 cm x 19 Kg)

• Eco-friendly: replaces far larger and more expensive spotlights
• Art-Net / RDM

• Electronic ballast fitted as standard
• Available in “mirror-finish” chrome version

Sharpy Wash 330 is an extraordinarily compact, lightweight 330 W washlight, with the luminous efficiency, graphic and optical performance of a 1000W fixture. It is extremely silent and quick, and fitted with a complete CMY color system, special colors, 6.5°-48° zoom, mechanical dimmer, beam shaping filter and motorized top-hat. At minimum beam angle, the Sharpy Wash 330 produces a beam like its brother Sharpy: the two lights are designed to work perfectly together. It is an eco-friendly light, allowing considerable running and consumption cost savings.

• New 330W Lamp (8,000 K 1,500 h)
• Equalling the light output of a 1,000 Watt luminaire
• Small, lightweight and easily transported: only 18.5 Kg (40.8 lbs)
• Adjustable beam angle from 6.5° to 48°
• Motorised Top Hat (Clay Paky patented)
• CMY Color System + 11-color wheel + open
• Rotating beam shaper
• High speed movements and effects
• Frosted, smooth mechanical dimmer
• High speed Stop/Strobo effect
• Soft-edge Filter + heavy frost filter
• New, high-performance electronics

• Art-Net / RDM

• Patented Italian design Eco-friendly: replaces far larger and more expensive washlights
• Electronic ballast fitted as standard
• Available in black, white, gold-plated and “mirror-finish” chrome plated versions
