Hasebase Base*Low*Pro

The baselowpro from hazebase is a CO2 low fogger like no other. Create amazing low lying fog when used with either the hazebase baseclassic or basehigh*power foggers.

Dense low fog
Automatic and user defined programs
Control through DMX, Ethernet or Analog
Operated with external CO2 bottle
Fog height controlled via adjustable air supply
Full Color touchscreen display

Easy to find and use, the baselowpro utilizes liquid CO2.

adjustable CO2 consumption per minute: 1kg, 2kg, 3kg

Hasebase Base*Low*Pro2021-10-11T12:54:05-07:00

Hazebase Highpower²

Compact design and powerful 3100W output are complemented by the efficient and variable output, this machine is designed for versatility, efficiency, and reliability. The Highpower2 reaches operation in less than 8 minutes. It can be controlled via DMX512, RDM, Modbus RTU or JT remote, or built-in onboard timer. Wired and wireless controllers are also available. Base Classic water-based fluid is designed for any environment. From a quick dissipation to a dense fog that will hang in the air. The unit can run continuously at 20%.

Hazebase Highpower²2025-12-16T14:13:34-07:00

Hazebase TOURING2

The Base Touring2 is the machine for the professional who needs ultimate output and control. The high-output units features a built-in 450W fan, allowing the dense output to be pushed further and quicker than previously seen.

Utilizing the clever air diverter positioned at the front of the unit, It now becomes a huge haze effect filling stadiums in a fraction of the time. The Base Touring2 reaches operation in less than 14 minutes. It can be controlled via DMX using only one channel or a built-in onboard timer. Wired and wireless controllers are also available.

Hazebase water-based fluid is designed for any environment. From a quick dissipation to a dense fog that hangs in the air. The unit can run continuously at 50%.

Hazebase TOURING22025-12-16T14:14:02-07:00

Hazebase The Fab

With THE FAB, Hazebase, known for professional fog machines, presents a revolutionary hazer. THE FAB offers a variety of possibilities to create atmospheric light effects even better. The directly heated vaporizer of THE FAB is up to operating temperature within 5 seconds.

Due to the adjustability of haze density, pump power, fan speed and angle of attack of the two air baffles, almost any desired haze density can be created. A newly developed vegan, highly concentrated fluid is used. This produces the finest droplets with maximum lifetime in the air. Its two extremely quiet and adjustable fans allow it to be used in areas where ambient noise is a nuisance.

The Hazer also offers countless control options. In addition to the direct operation on the device by means of a 2.8″ touch screen, the hazer can be controlled remotely via DMX with 3 channels, as well as via Ethernet (Art-Net TM and sACN). A wired remote control is available as an option.

As standard the Hazer THE FAB is mounted in a 19″ roadcase with 2U. The 1000ml fluid tank lasts from about 150 hours at minimum settings to 3 hours at maximum output.

Hazebase The Fab2024-03-11T14:08:16-07:00

HES Axon Media Server

banrAXONPRO

Single output media server capable of 4 layers of simultaneous HD playback and up to 10 layers of content and masks. Audio playback and a full warp engine have been included in the small for chassis making Axon HD the most compact and cost effective product in our range.

Features including Collage Generator™ and Curved Surface Support are also included as is the largest library of stock content available in the market. The stock content has been enhanced with the addition of new HD content, allowing users to create stunning visual environments without necessarily relying on expensive custom content.

Alongside the single graphics output is a dedicated output for the CMA.
For users needing capture functionality, an external capture device can be added.

HES Axon Media Server2021-10-12T09:35:50-07:00

HES Catalyst Media Server

catalyst

The Catalyst Media server is an image processing system that offers an unlimited range of DMX 512 controlled image processing effects.

Unlimited creativity
The Catalyst media server offers an incredible range of image processing tools. Controlled from DMX 512 it can process and manipulate high resolution graphics images, movies store on harddisk or live video images.

Use with Daylight Displays and Projectors
When used with Daylight Displays or Projectors, the Catalyst Media Server presents an unparallelled way to program, process and run content on the display to use it as a creative effects tool.

Complete
The Catalyst Media Server is delivered in a flight case that contains all processing equipment in a shock absorbing frame.

HES Catalyst Media Server2021-10-12T09:36:03-07:00

HES DL.3

banrDLHD

The DL.3 Digital Light integrates a media server loaded with a wealth of digital content with a high output 4-chip light engine, a highly sensitive HAD sensor camera and an infrared illumination system. DL.3 mounts like any other intelligent moving luminaire and controls just as easily with plug-and-play operation using standard DMX cabling and protocols. Production set-up time is reduced as there is no need for RGB cabling, and racks of servers are no longer necessary at front-of-house or backstage area.

A Content Management Application running on your MAC or PC workstation or laptop computer gives you remote control of uploading and crossloading content, upgrading software and fixture configuration for multiple DL.3 fixtures on a fixture network.

HES DL.32021-10-12T09:36:18-07:00

HES Showgun

hesShowgun

Distinctive in design, SHOWGUN 2.5 is, in essence, a very large and powerful automated light that can project images, change and mix dichroic colors, and switch from hard-edge to soft-edge all within a compact system.  This new version of SHOWGUN has 30 percent more photonic output than its predecessor.

SHOWGUN provides entertainment lighting design possibilities in three dimensions: first, in the air with high-energy focused or soft edge beams; second, with images projected on the stage surface; and third, at the SHOWGUN fixture itself by using an innovative LED Tracking System.

A new patent pending optical design is at the forefront of the “radical rethinking.” This optical design incorporates a proprietary, optically accurate polymer microfresnel lens allowing SHOWGUN to produce a true focused hard-edge or a brilliant soft-edge combination, without the need for two separate fixture types. The true focused hard-edge allows SHOWGUN to project HES LithoPattern images, while the soft-edge abilities exceed industry standards. Soft edge/hard edge “enabling” for SHOWGUN is easily accomplished from any lighting console.

SHOWGUN’s main output uses a 2500 watt short arc metal halide lamp designed as a joint venture between Philips and High End Systems. The MSR 2500/2 lamp uses a novel fast fit socket design that allows for a more compact reflector combination. Combining the high-performance lamp, advanced reflector and revolutionary optical design, SHOWGUN must be seen to be fully appreciated.

SHOWGUN’s LED Tracking System forces a double take as a unique homogenously mixed RGB LED circular array that allows the user to either match the color of the main output beam, or to project a complementary color by mixing RGB values. The LED Tracking System alone produces more than 5000 lumens of output, and works in tandem with SHOWGUN’s other features to redefine the rules of lighting design.

SHOWGUN is at the vanguard of today’s lighting design revolution.

Features

  • Proprietary Short Arc Lamp and optics produce 130,000 lumens of light
  • Variable soft-edge
  • fully rotating, indexable lithos
  • Variable iris
  • Variable strobe, Electronic strobe
  • Light Burst lamp boosting
  • Zoom range from 9°-18°
  • Remote focus
  • Full optical dimming and fade to black
  • Innovative LED Tracking Ring produces over 5000 lumens of RGB color. Homogenously mixed RGB LED circular array eliminates the multiple colored RGB look when white or mixed colors are produced.
  • Smooth CMY color mixing provides and infinite palette of color
  • Four indexing Litho/Gobo rotators
  • Black Light projection filter
  • TriColor effect supports independent color flag control
  • Tracking and Independent modes selectable via DMX
  • Optical encoders automatically correct the head’s position if manually moved

Operation

  • 420° pan and 216° tilt movement
  • Auto-switching power supply
  • Large dot matrix display allows for 2 lines of text
  • 200v-240v
  • 30 DMX channels
  • DMX Connector: 5-pin XLR
  • Compliances: ETL, CE

Construction

  • Modular construction
  • Fast service design for Reflector, Condenser and Output lens
  • Electronic cooling system control
  • Stunningly fast, smooth and quiet yoke movement using proprietary multi-phase technology
  • Performance oriented exterior design prevents stray light scatter
  • Pan and tilt locks for easy transportation.

Electrical Specifications/Light Source
Power Consumption: 16 Amps at 208 V, 13.75 Amps at 240V

Fixture Rated Power: 2500 W
Lamp: PHILIPS MSR 2500/2

Color Temperature: 7000K
Barco rated Lamp Life: 1250 hrs
CRI >80
CIE X=.320; Y=.330

HES Showgun2021-10-11T12:57:15-07:00

High End Systems Stage Hog

The Stage Hog is built for any production environment that demands a compact yet highly flexible solution. Featuring a ‘headless’ design, this powerful console is loaded with road-tested features including RGB-backlit keys, motorized faders, five precision encoders with assignable wheel buttons, and customizable user and function keys — all complemented by dual dashboard multitouch displays for a smooth and intuitive workflow.

A built-in backlit alpha keyboard housed in a locking drawer adds convenience and ease during programming.

Designed with versatility in mind, the Stage Hog includes two standard baby pin mounting points for third-party accessories such as monitors, tablets, or cameras.

Connectivity is robust with Neutrik EtherCON and OpticalCON, DMX, MIDI, SMPTE, and USB-A and USB-C ports, making the Stage Hog a versatile and powerful centerpiece for any modern lighting setup.

ETC Stage Hog Features

  • Neutrik powerCON® TRUE1 power input and thru
  • Two Neutrik EtherCON® Ethernet connections
  • Two Neutrik Multimode opticalCON Duo connectors
  • USB 3.0 type A (4) and type C (2) connectors
  • Wi-Fi and Bluetooth antennas
  • Four DMX outputs (5-pin XLR)
  • SMPTE input (3-pin XLR)
  • MIDI In/Thru/Out
  • Desk Light (3-pin XLR, standard pinout)

ETC Stage Hog Specifications

  • SYSTEM CAPACITY
    • 64 Universes
  • DISPLAY FUNCTIONS
    • Dual 12.5” dashboard displays; six full color function key displays
    • Supports two external display port monitors at 1280×1024 minimum resolution, with optional touch or multi-touch control
    • User configurable displays with recordable views
    • Dedicated views to access most-used items quickly
    • Palette, list, views, scenes, batches, effects directories
    • Programmer window
    • Plot views
    • Output window
    • Fixture Schedule and Patch windows, sortable by fixture or by universe
    • Three color schemes for daylight use, regular use or dark environment use
  • PROGRAMMING
    • Compact RGB backlit command keypad for quick programming
    • Command-line interface
    • Programmer Dashboard display for encoder mapping, command line/status display and additional programming tools
    • Programmer window displays selected and adjusted fixtures
    • Lists constructed with +, -, and Thru or selection softkeys, Next, Back and All commands
    • Intensity set with command keypad, full key, intensity palettes
    • Ordered groups
    • Comprehensive fanning using segments and buddying
    • 12 Function keys for user kinds and commands
    • Dedicated kind keys and five high-resolution parameter encoders, with two keys per encoder
    • Eight user “U-Keys” for user defined functions
    • Media picker window
    • Hog Color System
    • Programmer window
    • Groups for simplified fixture selection
    • Palettes: intensity, position, colour, beam, effects
    • Effects Engine
    • Pixelmapping Effects
    • Park
    • Undo command
    • Delete, Move and Copy commands
    • Highlight, lowlight and rem dim commands
    • Cue level and parameter level timing
    • Record, Update and Merge commands
    • Knockout and Clear commands
    • Set command for text labels and data entry
  • PLAYBACK CONTROLS
    • Playback Dashboard display for playback bar display, master ranges, and additional playback tools
    • 10 pageable, motorized RGB-backlit master playbacks with customizable faders, flash, go, halt, back and choose keys
    • Main playback stack including GM, Restart, Assert, Release, Pig, Skip Forward, Skip Backward, Master Pause, and Master Play keys
    • Master Ranges for quick reassignment of playback masters content
    • Unlimited fader Pages
    • Comment macros and keystroke macros
    • Paging keys
    • Virtual masters
    • Scenes
    • Batch controllers
    • Group masters
    • Triggering via Command keys
    • Playback expansion via Tour Wing
    • OSC input/output, MIDI messages, MIDI Show Conrol, MIDI/LTC timecode
  • INTERFACES AND ACCESSORIES
    • Gig Hog programming wing
    • HPU hybrid processing unit
    • Response network gateways and interfaces
    • ETCnomad
  • ELECTRICAL AND ENVIRONMENTAL
    • ETL, CETL and CE compliance
    • Mains power: 100–250 VAC, 50/60 Hz, max 80 W
    • Mains connector: Neutrik PowerCON® TRUE1
    • Breaker: 7.5 A
    • Acoustical rating: TBD dbA
High End Systems Stage Hog2026-02-11T09:32:23-07:00

High End Systems Tour Hog

The Tour Hog is purpose-built for any production environment that demands a compact, all-in-one control solution. Engineered for performance, it features a stand-alone design packed with proven, road-ready features including RGB-backlit keys, motorized faders, and five premium encoders with assignable wheel buttons. For complete control customization, it also includes user and function keys, dual dashboard multitouch displays, and a 24-inch articulating high-resolution multitouch screen for an immersive programming experience.

A built-in backlit alpha keyboard tucked into a locking drawer adds convenience and speed for live operation.

The Tour Hog offers robust connectivity with Neutrik EtherCON and OpticalCON, along with DMX, MIDI, SMPTE, and both USB-A and USB-C ports, ensuring it integrates seamlessly into any modern lighting rig.

ETC Tour Hog Features

  • Neutrik powerCON® TRUE1 power input and thru
  • Two Neutrik EtherCON® Ethernet connections
  • Two Neutrik Multimode opticalCON Duo connectors
  • USB 3.0 type A (4) and type C (2) connectors
  • Wi-Fi and Bluetooth antennas
  • Four DMX outputs (5-pin XLR)
  • SMPTE input (3-pin XLR)
  • MIDI In/Thru/Out
  • Desk Light (3-pin XLR, standard pinout)

ETC Tour Hog Specifications

  • SYSTEM CAPACITY
    • 64 Universes
  • DISPLAY FUNCTIONS
    • Built-in articulating 23.8” high resolution multitouch displayand dual 12.5” dashboard displays; six full color function key displays
    • Supports two external display port monitors at 1280×1024 minimum resolution, with optional touch or multi-touch control
    • User configurable displays with recordable views
    • Dedicated views to access most-used items quickly
    • Palette, list, views, scenes, batches, effects directories
    • Programmer window
    • Plot views
    • Output window
    • Fixture Schedule and Patch windows, sortable by fixture or by universe
    • Three color schemes for daylight use, regular use or dark environment use
  • PROGRAMMING
    • Compact RGB backlit command keypad for quick programming
    • Command-line interface
    • Programmer Dashboard display for encoder mapping, command line/status display and additional programming tools
    • Programmer window displays selected and adjusted fixtures
    • Lists constructed with +, -, and Thru or selection softkeys, Next, Back and All commands
    • Intensity set with command keypad, full key, intensity palettes
    • Ordered groups
    • Comprehensive fanning using segments and buddying
    • 12 Function keys for user kinds and commands
    • Dedicated kind keys and five high-resolution parameter encoders, with two keys per encoder
    • Eight user “U-Keys” for user defined functions
    • Media picker window
    • Hog Color System
    • Programmer window
    • Groups for simplified fixture selection
    • Palettes: intensity, position, colour, beam, effects
    • Effects Engine
    • Pixelmapping Effects
    • Park
    • Undo command
    • Delete, Move and Copy commands
    • Highlight, lowlight and rem dim commands
    • Cue level and parameter level timing
    • Record, Update and Merge commands
    • Knockout and Clear commands
    • Set command for text labels and data entry
  • PLAYBACK CONTROLS
    • Playback Dashboard display for playback bar display, master ranges, and additional playback tools
    • 10 pageable, motorized RGB-backlitmaster playbacks with customizable faders, flash, go, halt, back and choose keys
    • Main playback stack including GM, Restart, Assert, Release, Pig, Skip Forward, Skip Backward, Master Pause, and Master Play keys
    • Master Ranges for quick reassignment of playback masters content
    • Unlimited fader Pages
    • Comment macros and keystroke macros
    • Paging keys
    • Virtual masters
    • Scenes
    • Batch controllers
    • Group masters
    • Triggering via Command keys
    • Playback expansion via Tour Wing
    • OSC input/output, MIDI messages, MIDI Show Conrol, MIDI/LTC timecode
  • INTERFACES AND ACCESSORIES
    • Gig Hog programming wing
    • HPU hybrid processing unit
    • Response network gateways and interfaces
    • ETCnomad
  • ELECTRICAL AND ENVIRONMENTAL
    • ETL, CETL and CE compliance
    • Mains power: 100–250 VAC, 50/60 Hz, max 80 W
    • Mains connector: Neutrik PowerCON® TRUE1
    • Breaker: 7.5 A
    • Acoustical rating: TBD dbA
High End Systems Tour Hog2026-02-11T09:34:23-07:00
